Justrite 35222 Gas Cylinder Forklift Pallet with Firewall - 12 Cylinder Capacity - End Loaded

Justrite 35222 Gas Cylinder Forklift Pallet with Firewall - 12 Cylinder Capacity - End Loaded

Transport multiple gas cylinders securely with a forklift using these end-load oriented pallets. Secure a group of gas cylinders using the two included 10,000-lb (4,536-kg) DOT compliant straps that attaches to frame at either 12-, 24- or 36-in (305-, 610- or 915-mm) from the deck. Fully welded construction from 11-gauge (3-mm) hot-rolled steel and structural tube steel, powder-coated to ensure longevity and chemical resistance.

†Marinite® I is a registered trademark of BNZ Materials, Inc.

• Steel encased Marinite® I† creates a one-hour fire barrier between the fuel and oxidizer—exceeds minimum NFPA 55, OSHA and CGA standards
• Fully enclosed 7.75-in wide (197-mm) forklift channels with two way access
• Textured finish on the pallet provides a non-skid surface

Specs:

• Model No.: 35222
• Cylinder Capacity: Varies
• Cylinder Capacity with Max Cylinder Dia: (12) 9 inch, (6) 12 inch, or (2) 21 inch
• Firewall Rating: One-Hour
• Mount Type: Forklift
• Weight Capacity (lb): 4000
• Weight Capacity (kg): 1814
• Strap Style: Ratchet Binding - 1 Per Side
• Straps Per Cylinder: 1 Total
• Material Specifications: Steel/Marinite® I
• Complies with NFPA 1 Fire-Code: Yes
• NFPA 55: Yes
• OSHA Compliance: Yes
• CGA: Yes
• Net Weight, lbs: 384
• Net Weight, kg: 174
• Net Dimensions (W x D x H): 32 x 48 x 78 inches
• 813 x 1219 x 1981 mm

* Note: No Tanks Included
