Genie AWP-20S Aerial Standard Base Work Platform 20' - DC Powered
- 10+
Estimate Shipping
Description
The Genie AWP-20S Super Series aerial work platform lifts one worker to a 20 ft 1 in platform height (26 ft 1 in working height) with a 350 lb capacity. The 2 ft 5 in wide base rolls through a standard doorway, and one person can set up, position, and operate the lift - the included outriggers have interlocks that confirm correct installation before the platform will raise.
DC powered - onboard 12V battery with worldwide smart charging system. The patented mast is built from aircraft-quality aluminum - the most rigid in its class - and the rocker base system maneuvers around and over obstacles while the small outrigger footprint positions the platform close to walls and racking. A GFI receptacle on the platform (ANSI/CSA models) powers tools at height.
- 350 lb platform capacity, single occupant
- DC powered - onboard 12V battery with worldwide smart charging system
- Ground and platform controls with auxiliary platform lowering
- 2 ft 5 in width rolls through standard doorways
- Compact stowed footprint loads easily for transport
- Super-Straddle option (sold separately) to work over fixed seating
- ANSI A92.20 and CSA B354.6 compliant; 5-year warranty
| Platform height | 20 ft 1 in |
| Working height | 26 ft 1 in |
| Capacity | 350 lb |
| Power | DC (12V battery + smart charger) |
| Width | 2 ft 5 in |
| Platform size | 27 x 26 in |
| Unit weight | 766 lb |
| Standards | ANSI A92.20, CSA B354.6 |
Industrial Products is an authorized Genie dealer. Every lift ships via LTL freight with liftgate delivery available; order online or call our lift experts for a freight quote or volume pricing.
Specifications
| Platform Height | 20'1" |
|---|---|
| Lift Capacity | 350 lbs |
| Power | DC |
| Platform Dimensions | 27" x 26" |
| Working Height | 26'1" |
