The Yellow Jacket® 5-channel AMS® (Advanced Modular System) is a patented technology that utilizes separate cable protector sections and ramps to create a system that is fully expandable to hold an unlimited number of cables. By detaching the ramps, you can also quickly add cable runs and ADA compatible side ramps to existing systems. The Yellow Jacket® AMS® readily handles heavy truck and bus traffic while providing easy access for pedestrians, carts, and wheelchairs. Hinged lids make for easy loading of cables and hoses. View More
Estimate Shipping
Loading...
Checkers Safety Group Heavy-Duty Yellow Jacket Cable Protectors
| Model Number | Description | Channels | Capacity | Length | Width | Price | Qty |
|---|---|---|---|---|---|---|---|
| YJ1-500-Y/B | Straight Section with Built in Ramps | 9,435 lbs | 36" | 27" |
$1,596.15
|
|
|
| YJ3-225-Y/B | Straight Section with Built in Ramps | 14,210 lbs | 36" | 20" |
$453.29
|
|
|
| YJ3EB-225-Y | End Caps (pair) | 14,210 lbs | 6" | 20" |
$223.68
|
|
|
| YJ3TL-225-Y/B | Left Turn | 14,210 lbs | 25" | 20" |
$346.11
|
|
|
| YJ3TR-225-Y/B | Right Turn | 14,210 lbs | 25" | 20" |
$346.11
|
|
|
| WSA-225-BFF-BLU | AMS Female Ramp | 14,210 lbs | 35.5" | 37.75" |
$351.29
|
|
|
| WSA-225-BFM-BLU | AMS Male Ramp | 14,210 lbs | 35.25" | 2.75" |
$351.29
|
|
|
| WSA-225-KIT1-HS | Ramp Kit 1 | 14,210 lbs | 35.25" | 2.75" |
$1,845.47
|
|
|
| WSA-225-KIT2-HS | Ramp Kit 2 | 14,210 lbs | 35.25" | 2.75" |
$1,078.38
|
|
|
| WSA-225-RFAH-DY | AMS Female ADA Ramp | 14,210 lbs | 35.25" | 2.75" |
$457.59
|
|
|
| WSA-225-RMAH-DY | AMS Male ADA Ramp | 14,210 lbs | 35.25" | 2.75" |
$457.59
|
|
|
| YJ3-225-AMS-Y/B | AMS System - 1 Center Section & 1 Pair of Ramps | 14,210 lbs | 39" | 18.61" |
$455.01
|
|
|
| YJ3-225AMSCTRYB | Center Section - No Tapered Sides | 14,210 lbs | 36" | 9.87" |
$306.26
|
|
|
| YJ3-225-AMS-F-B | AMS Female Ramp | 14,210 lbs | 39" | 5.5" |
$144.17
|
|
|
| YJ3-225-AMS-M-B | AMS Male Ramp | 14,210 lbs | 39" | 4.7" |
$147.00
|
|
|
| YJ4-125-Y/B | Straight Section with Built in Ramps | 16,300 lbs | 36" | 18" |
$333.47
|
|
|
| YJ4EB-125-Y | End Caps (pair) | 16,300 lbs | 6" | 18" |
$143.52
|
|
|
| YJ5-125-Y/B | Straight Section with Built in Ramps | 16,300 lbs | 36" | 20" |
$330.77
|
|
|
| YJ5-400-Y/B | Extreme Heavy Duty Straight Section with Built in Ramps | 7,990 lbs | 35.25" | 2.75" |
$2,435.15
|
|
|
| YJ5-125AMSCTRYB | Center Section - No Tapered Sides | 16,300 lbs | 39" | 11.75" |
$252.24
|
|
|
| YJ5EB-125-Y | End Caps (pair) | 16,300 lbs | 6" | 20" |
$153.76
|
|
|
| YJ5TL-125-Y/B | Left Turn | 16,300 lbs | 25" | 20" |
$209.05
|
|
|
| YJ5TR-125-Y/B | Right Turn | 16,300 lbs | 25" | 20" |
$209.05
|
|
|
| YJ5X-125-Y/B | 4-Way Cross | 16,300 lbs | 19" | 20" |
$449.77
|
|
|
| YJ5I-125-M-Y/B | Male Interconnect | 16,300 lbs | 18" | 22.5" |
$196.76
|
|
|
| YJ5I-125-F-Y/B | Female Interconnect | 16,300 lbs | 18" | 22.5" |
$196.76
|
|
|
| YJ5-125-AMS-Y/B | AMS System - 1 Center Section & 1 Pair of Ramps | 16,300 lbs | 39" | 19.75" |
$350.08
|
|
|
| YJ5-125-AMS-M-B | AMS Male Ramp | 16,300 lbs | 39" | 5" |
$98.42
|
|
|
| YJ5-125-AMS-F-B | AMS Female Ramp | 16,300 lbs | 39" | 5.125" |
$100.57
|
|
|
| YJ5-125-ADA-Y/B | ADA Straight Section with Built in Ramps - Black/Yellow | 10,500 lbs | 20" | 50" |
$315.00
|
|
|
| YJ5-125-ADA-B/B | ADA Straight Section with Built in Ramps - Black | 10,500 lbs | 20" | 50" |
$308.95
|
|
|
| YJ5-125ADAY/BLU | ADA Straight Section with Built in Ramps - Blue/Yellow | 10,500 lbs | 20" | 50" |
$308.95
|
|
|
| WSA-125-KIT1-HS | Ramp Kit 1 | 16,300 lbs | 53.7" | 108" |
$1,467.48
|
|
|
| WSA-125-KIT2-HS | Ramp Kit 2 | 16,300 lbs | 53.7" | 72" |
$1,093.95
|
|
|
| WSA-125-KIT3-HS | Ramp Kit 3 | 16,300 lbs | 53.7" | 72" |
$644.80
|
|
|
| WSA-125-RFAH-DY | AMS Female ADA Ramp | 16,300 lbs | 38" | 20.5" |
$242.15
|
|
|
| WSA-125-RMAH-DY | AMS Male ADA Ramp | 16,300 lbs | 37.5" | 20.25" |
$229.64
|
|
|
| WSA-125-BFF-BLU | AMS Female Side/Corner Ramp | 5 | 16,300 lbs | 20.6" | 18" |
$182.67
|
|
| WSA-125-BFM-BLU | AMS Female ADA Side/Corner Ramp | 16,300 lbs | 20.6" | 18" |
$182.67
|
|
Description
Checkers Safety Group Heavy-Duty Yellow Jacket Cable Protectors
The Yellow Jacket® 5-channel AMS® (Advanced Modular System) is a patented technology that utilizes separate cable protector sections and ramps to create a system that is fully expandable to hold an unlimited number of cables. By detaching the ramps, you can also quickly add cable runs and ADA compatible side ramps to existing systems. The Yellow Jacket® AMS® readily handles heavy truck and bus traffic while providing easy access for pedestrians, carts, and wheelchairs. Hinged lids make for easy loading of cables and hoses.
Features:
- Protects cables and hoses
- Connect unlimited center sections and add ramps
- Hinged lid for easy cable placement
- Patented technology with modular interlocking design
WARNING: This product can expose you to chemicals including Carbon Black, Titanium Dioxide, Formaldehyde, and Benzyl Butyl Phthalate, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
