Garlock LifePoint STOP Single Tie-Off Point Anchors
LifePoint™ STOP System Single Person Fall Arrest
The Life-Point safety harness offers a non-penetrating single tie off anchor that works on flat surfaces (single ply membrane, BUR, concrete, TPO, and EPDM) with a maximum 5-degree incline. Meets fall-arrest ratings for one person. Modular design sets up quickly with no component over 30 pounds. Optional Transport cart allows repositioning quickly without disassembly. Corrosion-resistant for long-term usage.
The new LifePoint Single Tie Off Point (STOP) is the perfect safety harness solution for fall protection when circumstances require non-penetrating versatility. The LifePoint personal fall arrest system is a free-standing anchor point that can be placed on flat surfaces with a maximum incline of 5%. LifePoint can be repositioned in a few minutes by one person.
Features:
- Mobile Fall tie-off anchor point that provides fall arrest for one person
- Meets OSHA Requirement 1926.502(d)
- Non-Penetrating design protects surface integrity
- Modular design has no component over 30 lbs. for quick easy assembly
- Optional transporter allows fast re-positioning without disassembly
- Bottom plates are coated with a resilient material to provide required friction coefficient with roof and as an added benefit will protect roof surfaces from contact with metal parts.
- Dee ring can be used to hoist anchor to the roof
- Base Dimensions: 30" x 30" x 12" (LxWxH)
- Weight Fully Assembled: 765 lbs
- Counterweights: 26 lbs each (24 required)
Optional LifePoint™ Transport Cart
Reposition LifePoint™ system on the jobsite.
Flat-free tires standard.
The new LifePoint™ ballast weight tie-off is the perfect solution for fall protection when circumstances require non-penetrating versatility. LifePoint™ provides the answer with an easy to set up and quick-move solution.
Non Penetrating Versatility: LifePoint™ is a free standing counter weight design that can be placed on flat surfaces with a maximum incline of 5%. Tested and approved for multiple surfaces such as single ply membrane, BUR, concrete, TPO and EDPM. LifePoint™ meets fall-arrest ratings for one person weighing up to 310 lbs (including equipment).
Modular Design: LifePoint™ is a modular design makes installation easy. The base is set in place and the individual counterweights are added into position. The center anchor provides safe, simple and rugged use.
Mobility: LifePoint™ can be repositioned in a few minutes by one person. With the patented transport cart, LifePoint™ can be moved to a new location quickly and safely by a single person.
Built to Last: Whether you transport LifePoint™ job to job or use it as a permanent tie of on your rooftop, with galvanized components LifePoint™ will perform for years.
